Bending Plates
Bending Plates
SPECIFICATION
- Bending Plate dimension : 1500mm/1750mm
- Capacity : 30T /40 T Axle load
- Accuracy in static : ± 0.1% FSR @ Static
- Rated Axle load : ≥ 30T/40 T
- Safe overload : 150%
- Maximum passing speed : 50Kmph
- Static Accuracy : OIML Class III
- Dynamic Accuracy : ± 7%FSR @ 50Kmph
- Operating temperature : Up to 65 degree Centigrade
- Power Source : 230 V AC
- Relative Moisture : 95% RH
- Controlling device protection class : IP65
Application
- Highway toll projects Infrastructure
- Coal, iron ore, Railway yard
- Lose materials loading ond unloadingTransportation.
- Cement and steel manufacturing
- Process Row material transportation
